推臺尺寸 Dimension of sliding table

3200×410mm

最大鋸切長度 Gross cut capacity

3200mm

鋸片角度 Tilting saw blade

0-45°

劃線鋸直徑 Scoring saw blade diameter

120mm

最大鋸切寬度 Width of cut between saw blade and rip fence

1250mm

劃線鋸轉速 Scoring saw speed

7000-8000rpm

最大鋸切厚度 Max. cutting thickness(300/400mm)

300/400mm)

鋸片直徑 Main saw blade diameter

300mm(350-400mm)

副軸直徑 Scoring spindle diameter

20mm

副電機功率 Scoring motor power

1.1KW

主鋸轉速 Main saw speed

4500/6000rpm

毛重 Weight

1050kg

主軸直徑 Main spindle diameter

30mm

外形尺寸 Overall dimension

3350×3350×900mm

主電機功率 Main motor power

5.5KW
